技术参数：

◆1.外形尺寸：2780×3100×1890MM

◆2.布  速：0～100M/MIN

◆3.电源电压：380V

◆4.电机功率：3KW

◆5.工作宽度：2300～3000MM

◆6.最大卷径：500MM

◆7.对边精度：±5MM

◆8.计长精度：≤0.5%

技术特点/Features:

◆1.适用于纺织印染企业，主要针对针织布料的质量检测；

Applicable for the quality inspection Knitted fabric for textile, printing, and dyeing enterprises.

◆2.红外线探边自动追踪，自动对齐布边，无布自动停机；

Infrared ray detects the edge of the automatic tracking, automatic alignment of the edge of the cloth, no cloth automatic shutdown.

◆3.前后自动张力架控制，使布匹在卷验中不受张力影响；

Automatically control the front and back tension frame, protect the fabric from the influence of tension when rolling.

◆4.前后打边装置，使布匹不会皱褶和卷边，另配吹边装置；

Front and back selvedge device, prevent crease and rolling with edge blowing device.

◆5.变频调速，操作简便，并可另配电子秤；

Frequency conversion speed control, easy to operate, and can be equipped with another electronic scale.

◆6.裁布刀/自动裁布刀可供选择，不锈钢分体/一体工作台可选；

Cutting knife/automatic cutting knife available, Stainless steel split/integrated table available.

◆7.卷布辊配差速器，调节布卷软硬度。

Fabric roller is equipped with speed differential mechanism, adjust the softness and hardness of fabric roll easily.
