技术参数：

◆1.外形尺寸：13785×4750×4750MM

◆2.布  速：300～500M/MIN

◆3.电源电压：380V

◆4.电机功率：135KW

◆5.工作温度：120度以下

◆6.材  料：不锈钢

◆7.全机重量：12000～1400Kg

◆8.空压机压力：4-7Kg

技术特点/Features:

◆1.本机是一种用于对不同织物（梭织和针织）进行非连续加工的机器，该设备可按预先设计的步骤对织物进行干燥、熏蒸、清洗和传递；

This is a machine for non-continuous processing of different fabrics (woven and knitted),The machine dries, fumigates, washes and passes the fabric in pre-designed steps.

◆2.布料的牵引通过离心风机产生的气压来完成的；

Fabric pulling is accomplished by air pressure generated by centrifugal fans.

◆3.在烘干期间，部分空气被回收和循环以达到充足的能量节约；

During drying, part of the air is recovered and recycled to achieve sufficient energy savings.

◆4.落布装置是一个圆柱形滚筒，滚筒表面覆盖着硅材料涂层目的是为了保证各种质量的布料和织品有一个极好的附着贴合；

The machine shell has insulated rock wool to save energy and is equipped with a temperature-resistant high-pressure fan.

◆5.设备可提供不同的且可改变的空气加热系统：一个蒸汽热交换器或者一个热煤油热交换器；

The equipment can be supplied with different and changeable air heating systems: a steam heat exchanger or a thermal kerosene heat exchanger.

◆6.机器材质为不锈钢板材，并配耐温高压风机。

The machine is made of stainless steel plate and is equipped with a temperature-resistant high-pressure fan.
