技术参数：

◆1.外形尺寸：4050×2924×2420MM

◆2.布  速：0～35M/MIN

◆3.电源电压：380V

◆4.电机功率：6.75KW（传动电机）

◆5.工作宽度：2500MM

◆6.针  距：5～15MM

◆7.空压气要求：6-8KG/CM3

技术特点/Features:

◆1.该机器专门用于针织物染色前折叠后的缝边和钉边，尤其适用于预染后的橡胶弹性织物（LYCRA、剪毛织物）；

The machine is specially designed for sewing and pinning the edges of knitted fabrics after folding before dyeing, especially for rubberized elastic fabrics (LYCRA, shearling) after pre-dyeing.

◆2.红外线电眼感应自动追踪液压对边对折；

Infrared electric eye sensor automatic tracking hydraulic edge-to-edge folding.

◆3.进布自动中心校正，并附分丝扩幅辊将布展平；

Automatic center correction of incoming fabrics, with slit spreading rollers to flatten the fabrics.

◆4.采用进口缝纫机头，日本关西KANSAI；

Imported sewing machine head, Japanese KANSAI.

◆5.变频、PLC同步控制，运行稳定；

Frequency conversion, PLC synchronous control, stable operation.

◆6.板条纠偏，配一台单线机头。

Slat guiding with one single line head.
