技术参数：

◆1.外形尺寸：2780×3300×2000MM

◆2.布  速：0～100M/MIN

◆3.电源电压：380V

◆4.电机功率：2.2KW

◆5.工作宽度：2500MM

◆6.最大卷径：500MM

技术特点/Features:

◆1.适用于纺织、制衣企业检验化纤、纯棉等各种面料质量的检测；

Applicable to textile, clothing enterprises to test the quality of chemical fiber, cotton and other kinds of fabric testing.

◆2.红外线探边自动追踪，自动对齐布边，无布自动停机；

Infrared ray detects the edge of the automatic tracking, automatic alignment of the edge of the cloth, no cloth automatic shutdown.

◆3.前后罗拉，使布匹不会皱褶和卷边，可选配吹边装置；

Front and back fabric extending roller, prevent crease and rolling with edge blowing device.

◆4.变频调节打卷速度；

Control rolling speed with Frequency Converter.

◆5.散布进布架，自动松布可选配；

Dispersion feed frame, automatic loosening of cloth optional.

◆6.裁布刀/自动裁布刀可供选择；

Bulk fabric feeding frame or amplitude device can be installed , automatically loosen fabric is optional.
